Specs:
| Model No: | K4 |
| Input voltage: | AC 100~240V / DC 10~34V |
| Output voltage: | DC 1~34V |
| Max. input current: | DC 45A |
| Max. charging power: | AC 400W total between the two channels / DC 600W ×2 |
| Max. Discharging power: | 30W ×2 |
| Parallel charging power/current: | 800W/35A |
| Parallel discharging power/current: | 60W/3A |
| Supported battery types and cell count: | LiFe,LiIon,LiPo 1~8S;LiHv,ULiHv 1~7S; Pb 1~14S;NiMH/Cd 1~18S |
| Charging current: | 0.2~20.0A ×2 |
| Discharging current: | 0.2~3.0A ×2 |
| Balance current: | 1.5A/Cell Max |
| Abnormal voltage alarm: | Support |
| Incorrect cell count setting alarm: | Support |
| Support Working temperature: | 0~40℃ |
| Storage temperature: | -20~60℃ |
| Dimension: | 176×183×57mm |
| Weight: | About 1230g |
Included:
1X ISDT K4 Charger
